Spiral Tube & Fittings

Spiral galvanised ductwork & fittings in a large range of sizes.

Our ductwork complies to DW144 standard. The UK recognised specification of how to manufacture and install ductwork. Spiral ducting is made for transporting air - it supplies fresh air into buildings and extracts excess/stale air out of buildings. Spiral duct is much more effective in terms of less air leaks then rectangular ducting due to less joints because of its large 3m lengths. Spiral ducting can be used to carry air up to temperatures of around 200â—¦c at a continual temperature and around 250â—¦c if the temperature is intermittent. If used above recommended temperatures, discolouring can happen and corrosion can occur.

We can offer advice over the phone or email. Other products not listed are also available so please enquire via email orders@alphatube.co.uk

View as Grid List
Sort by
Display per page

Spiral Tubing x 1.5mtr

Spirally wound tube made from galvanized steel. Manufactured and cut to 1.5 metre lengths. Female sizes, male fittings to fit inside. Available from 63mm – 710mm. Bigger sizes available by phone or email enquiries.

*Please note* some of the more uncommon sizes may have a larger lead time.

3MTR lengths are avalible to pick up in store.

Data Sheet



£0.00

90° Bends

90-degree bend to suit spiral tubing, made from galvanized steel. Male ends to fit in spiral ducting or flexible tube. Available in sizes ranging from 63mm – 710mm. Bigger sizes available by phone or email enquiries.

*Please note* some of the more uncommon sizes may have a larger lead time.

Data Sheets



£0.00

45° Bends

45-degree bends to suit spiral tubing, made from galvanized steel. Male ends to fit in spiral ducting or flexible tube. Available in sizes ranging from 63mm – 710mm. Bigger sizes available by phone or email enquiries.

*Please note* some of the more uncommon sizes may have a larger lead time.

Data Sheets

£0.00

Male Collar

Male collar made from galvanised steel. These collars are made to join lengths of spiral tube together or other female fittings. Available in sizes ranging from 63mm – 630mm. Bigger sizes available by phone or email enquiries.

*Please note* some of the more uncommon sizes may have a larger lead time





£0.00

Female Collar

Female collar made from galvanised steel. These collars are made to join male fittings together such as bends or tees. Available in sizes ranging from 63mm – 630mm. Bigger sizes available by phone or email enquiries.

*Please note* some of the more uncommon sizes may have a larger lead time.



£0.00

Flanged Spigot

Flanged spigot branch made from galvanised steel. A male connection to fit into spiral ducting, flexible tube etc. Available in sizes ranging from 63mm – 710mm. Bigger sizes available by phone or email enquiries.

*Please note* some of the more uncommon sizes may have a larger lead time.

Data Sheets



£0.00
